IC-LL-132-70W-UGR-SQ



● Flicker-free, visual comfort
● Uniform illumination, direct and indirect light
● Outstanding glare control
● Modernization design, ideal for office and education lighting
● Support human centric lighting control, blue tooth control
● Support tunable CCT, presence & daylight sensor
● Reception and open area for office
● Education
● High-end restaurant etc
· Lumen:
7000lm(50%Up, 50%Down)
7000lm(30%Up, 70%Down)
CCT: 2700K-6500K
CRI: 80Ra,90Ra
UGR: <16
SDCM: <=3
· Wattage: 70W
Efficacy: 100lm/W
Voltage: 200-240V
Download Documentation

Overall


Specifications

Model

LED

(Pcs)

Wattage

(W)

Colour

Lumens

(Lm)

Size

(mm)

Beam

Angle(°)

Input

Voltage(V)

Waterpriif

(IP)

Download

Highlight
Size: 1325mm (Length)
Color: White, silver
Finish: Powder coated
Material: Profile: Extruded aluminum
Optic: PMMA

Lifespan: 50000h(L90, Tc=55℃)
IP Protection: IP20
